The family of P1 PUNCH speakers were engineered to fit and built to put you in control. The vehicle-specific adapters and redesigned frame geometry ensures seamless integration and installation. A larger motor, precision-tuned tweeter configurations, and ultra-durable materials deliver relentless output and uncompromising reliability.

Auto Fit Architecture: Everything was engineered to fit. A re-designed frame, mounting holes, removable motor cover and speaker diameter were all engineered to ensure seamless integration into today’s modern vehicles. the Factory Location Woofer Ring (F.L.W.R.) and mounting flanges provide a flexible yet precise alignment for drop-in integration into most factory mounting locations.

Superior Flexibility: No matter the application, the PUNCH series offers exceptional flexibility for your build. Every detail has been carefully considered, from frame geometry to mounting holes and diameter all to ensure a seamless fit in most modern vehicles and to make installation as smooth and adaptable as possible.

Performance Driven: Powered by the advanced VAST 2.0& technology, the PUNCH series delivers a 25% increase in cone area, resulting in maximum output and deeper, more impactful bass. The Tru-Sight& tweeter ensures precise high-frequency alignment, so every note comes through with clarity and accuracy. Rated at 75W RMS and 150W peak, PUNCH speakers deliver the output you demand, loud, clean, and relentless.

Built to Last: Every component. Every material. Chosen for strength. Built for the long haul. From reinforced carbon fiber baskets to Santoprene& surrounds and Nomex® spiders, every part of the PUNCH speaker is engineered to be a workhorse. No matter how hard you drive them, the class-leading construction delivers relentless performance that lasts.

Engineered to Fit. Built to Perform.

The P1 PUNCH speakers are simple, all-in-one upgrades for standard factory systems. The P1 are perfect for Basic OEM systems with single-speaker locations in doors or rear decks. Factory single cone drivers don’t have tweeters and replacing them with a 3-way coaxial will deliver a big leap in sound clarity and "punch".

Kit Includes:

• (2) 2.5" 4Ω Coaxial Speakers
• (2) Bass Blockers
• (2) OEM Adaptors
• Installation Hardware

COMSOL Multiphysics

COMSOL software analyzes complex physical phenomena (Multiphysics) that uses FEM (Finite Element Method) to analyze structure strength, heat flow, and electromagnetics, while FFT (Fast Fourier Transform) converts the speaker’s acoustical output into frequency components to show amplitude across bass, midrange, and treble ranges.

Auto Fit Architecture

Everything was engineered to fit. A re-designed frame, mounting holes, removable motor cover and speaker diameter were all engineered to ensure seamless integration into today’s modern vehicles. the factory location mounting flanges provide a flexible yet precise alignment for drop-in integration into most factory mounting locations.

Spiderless Piezo Tweeter

The 9mm polypropylene piezo super-tweeter eliminates the need for a conventional spider by utilizing magnetic ferrofluid in the voice coil gap. This fluid adheres to the coil, maintaining precise centering and stability during operation. Additionally, it acts as a thermal conductor, efficiently dissipating heat when the tweeter is driven at high output levels. This design improves reliability and ensures consistent high-frequency performance under demanding conditions.

VAST 2.0

The Vertical Attach Surround Technique delivers a 25% increase in cone area, resulting in maximum output and deeper, more impactful bass.VAST 2.0 updates the surround’s mounting location from an upside-down "T" shape to a "V" shape to increase the surround-to-frame gluing surface area in the pull-force direction.

Edge Driven Tweeter

The inverted dome tweeter incorporates an edge-driven voice coil, engineered for high-performance audio systems. The dome enhances clarity and precision in high frequencies, while the coil ensures superior power handling and broader sound dispersion. Together, they deliver an immersive high-frequency response ideal for a wide range of installation applications.

F.L.W.R.

The Factory Location Woofer Ring (F.L.W.R.) and mounting flanges provide a flexible yet precise alignment for drop-in integration into most factory mounting locations.

Tru-Sight

Tru-Sight tweeter ensures precise high-frequency alignment, so every note comes through with clarity and accuracy. This technology aligns the industry’s first lower 1/3 co-witnessed, 2-way tweeter configuration so they complement each other’s acoustical output, creating a unified and balanced soundstage.

UV Inhibitor Materials

Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in accordance with ASTM D4329 testing and certification procedures.

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

ICC Crossover

The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier installation.

CTA-2031

Power handling on Rockford Fosgate speakers conform to CTA-2031 industry standards.

Vibration Resistant

Components are able to withstand shock and vibration conditions common with outdoor vehicles.

Specifications:

• CTA-2031 Compliant
• Speaker Type: Coaxial
• Midrange Size (Nominal Diameter): 2.5"
• Tweeter Size (Nominal Diameter): 3/4" (19 mm) Inverted Dome
• Piezo Size (Nominal Diameter): 3/8" (9 mm) Co-Witnessed Convex
• Nominal Impedance (Ohms): 4Ω
• Voice Coil Diameter (in/mm): 1" (25.4 mm)
• Frequency Response (Hz): 150Hz - 25kHz
• Crossover: Tweeter High-Pass: 9kHz @ 6 dB/Octave Midrange Bass Blocker: 1,200Hz @ 6 dB/Octave (33µF)
• Fs (Hz): 200 Hz
• Power Handling (Watts RMS): 75 Watts RMS 150 Watts Peak
• Sensitivity (dB @ 1W/1M): 82 dB
• Sensitivity (2.83V/1M): 85 dB
• Cutout Diameter: 2.54" (64.5 mm)
• Rear-Loading Depth (Twist-Lock Adaptor): 1.47" (37.3 mm)
• Front-Loading Depth (Twist-Lock Adaptor): 1.6" (40.6 mm)
• Mounting Depth (With Motor Cover): —
• Min. Mounting Depth (No Motor Cover): —
• Front Side Clearance: 0.32" (8.2 mm)
• Grille/Trim Ring Included: No
• Removable Motor Cover: No
• Mounting Hardware: Yes

Included in the Box:

• (2) 2.5" 4Ω 3-Way Coaxial Speakers
• (2) 2.5" Twist-Lock Speaker Adaptors
• (1) 2.5" Speaker Cutout Templates
• (2) 33µF Non-Polarized Cap (Bass-Blockers)
• (4) Self-Tapping Phillips #8x32mm (Speakers)
• (2) 18 AWG Red/Black Speaker Wire, 205 mm
• (3) 18 AWG (–) Female Spade Conn. (.187")
• (3) 18 AWG (+) Female Spade Conn. (.250")
• (4) 18 AWG Crimp Butt Connectors
