Amplifier Tech Data :

• Channels: 1
• Class: D-Class
• Hi Level Input: Yes
• Low Level Input: Yes
• Digital Input: No
• Power supply voltage / fuse: 11 15 VDC / 2 x 30A
• Operating power supply voltage: 6.5 17 VDC
• Idling current: 1.3 A
• Idling current when off: 0.05 mA
• Consumption @ 14.4 VDC, 2?, Max Musical Power: 50 A
• Remote IN: 6.5 15 VDC (1 mA)
• ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable): 2 7 VDC

Amplifier Stage :

• Distortion - THD @ 100 Hz, 4?, 70% Rated Power: 0.1%
• Bandwidth A: (-3 dB, 2 VRMS, 4 ?): 10 Hz 500 Hz
• S/N ratio A: (A weighted @ 1 V): 110 dBA
• Damping factor A: (100 Hz, 4?, 2 VRMS): 140
• Input sensitivity Pre-In: Selectable: 0.6 - 2.0 - 6.0 VRMS
• Input sensitivity Speaker-In: Selectable: 2.0 - 6.5 - 20 VRMS
• Total Power RMS: 1000 W
• Minimum load impedance: 1?
• Output Power (RMS) @14.4 VDC, 1% THD:
  1Ch @ 4? 500 W x 1
  1Ch @ 2? 800 W x 1
  1Ch @ 1? 1000 W x 1

• Adjustable Crossover: No

CEA Specifications :

• Output power @ 4?, 1% THD+N, 14.4 V: 500 W
• SN ratio (ref. 1W output): 81,5 dB

Inputs :

• Input Type: Pre-In Inputs RCA
• Filters Outputs: Speaker-In Inputs wired
• Filter Pass A: Mute (Energy Saving control) wired (active to groung)

Other :

• Other Fucntions: Ambient operating temperature range 0 C to 55 C (32 F to 131 F)
• Weight: 1.92 kg
