Odyssey PC545MJT AGM Battery
Part No.
PC545MJT
Special Price
$480.00
Regular Price
$491.99
You Save
2%
off RRP
Buy Now, Pay Later
4 payments of $120.00
Description
ODYSSEY Extreme Battery
Metal Jacket; internal threaded brass terminals with M6 SS bolts
Powersport vehicles need a powerful battery that’s built to take the constant pounding that comes with the territory, whether it’s is on land, sea, or snow.
The ODYSSEY battery can handle it. Featuring rugged construction and packed tightly with pure lead plates, the non-spillable AGM design ODYSSEY battery protects against the shock and vibration that can quickly destroy other batteries. And the pure lead plates mean more power-twice the overall power and three times the life of conventional batteries-up to 400 cycles at 80% depth of discharge!
Dimensions:
| Length | 9.50 in |
|---|---|
| Width | 6.90 in |
| Height (terminals included) | 8.80 in |
| Height (container) | 8.10 in |
| Weight | 50.00 lbs |
Specifications:
| Voltage | 12 |
| Pulse (5 second) Hot Cranking Amps (PHCA) | 460 |
| Cold Cranking Amps (CCA) | 150 |
| HCA | 280 |
| MCA | 220 |
| 20Hr Nominal Capacity (Ah) | 13 |
| 10Hr Nominal Capacity (Ah) | 12 |
| Reserve Capacity Minutes | 18 |
| Terminal | M6 Receptacle |
| Torque Spec in-lbs (Nm max) | 50 (5.6) |
| Internal Resistance (mΩ) | 10 |
| Short Circuit (A) | 1200 |
| Operating Temperature Range | -40°F / -40°C to 176°F / +80°C |
| Optimum Storage Temperature | 68°F / +20°C |
