Specifications:

• Rated Line Pull 9500lb (4309kg)
• Motor (12v) 4.6KW/6.1HP; (24v) 6.5KW/8.7HP
• Gear Train Full Steel 3 Stage Planetary
• Gear Ratio 184:1
• Brake Automatic Load Holding
• Cable Type Synthetic Rope or Steel Cable
• Cable Size Synthetic Rope: 10mmx25m; Steel Cable: 9.2mmx26m
• Drum Size 63MM X 226MM
• Mounting Bolt Pattern 254mm X 114.3mm (4X M10 Bolts)
• Overall Dimensions 542mm X 114.3mm X 199mm
• Remote Control Heavy Duty Handheld + Wireless remote
• Battery Leads 2 X 1.8M Heavy Duty Leads
• Finish Black Power Coat
• Shipping Weight With Synthetic Rope: 27.3kg / With Steel Calbe: 38.8kg
• Warranty Limited 5 Year Electrical and lifetime Mechanical Warrranty
