SPECIFICATIONS

• Rated Line Pull 12000lb (5443kg)
• Motor - Series Wound (12V) 4.0kW/5.4HP - IP67 Rated
• Gear Train Full Steel 3 Stage Planetary
• Gear Ratio 253:1
• Brake Automatic Load Holding in the gearbox
• Synthetic Rope 11mm x 26.5m
• Mounting Bolt Pattern 254mm x 114.3mm
• Overall Dimensions 553.5mm x 160mm x 200mm
• Remote Control 3.7m Handheld Remote/Wireless Remote
• Battery Leads Included. 2 x 1.8m Heavy Duty Leads
• Finish Black Powder Coat
• Net Weight 31.4kg
• Gross Weight 33.4kg (includes packaging)
• Warranty Limited Lifetime

This model features the newly designed gearbox with integrated ratchet braking system. The ENTIRE winch is IP67 rated. Another fantastic model crafted by Runva.

Ideal for most 4X4 applications. This winch will also fit into most winch compatible bars available in Australia today.
