Features / Specifications

• Detects Vehicle Ohm ? Requirements
• Designed for late model vehicles that display light failure warning.
• Corrects Fast Flashing Indicators
• IP67 Rated
• Voltage Range 9-32 Volt
• 5 Year Warranty
• 82mm x 64mm x 19mm

Fitting Instructions

Must be mounted on metal surface, the module can reach temperatures of over 100 degree Celsius. You may require up to 1 module per function on each side. The resistor should always be wired between the input wires of the lamp, Not the chassis of the vehicle or trailer! If fitted to the chassis, a bad earth connection is possible and can result in problems with the lighting system of the vehicle.
