Build Australia's Toughest Street Legal Leaf Sprung Toyota Hilux Dual Cab with a Superior Engineering Outback Explorer GVM Upgrade Kit.

THIS KIT IS INTENDED FOR BRAND-NEW PRE-REGISTERED VEHICLES AUSTRALIA-WIDE.

IN-SERVICE APPROVAL MAY BE AVAILABLE IN SOME STATES and TERRITORIES.

Supply, Fitment and Federal Approval are exclusively available through Superior Engineering or one of the Federally Approved Production Facilities.

The cost of Fitting/Welding and Engineering Approval at any Superior Engineering Production Facility Location Before First Vehicle Registration Starts from $5500.00 Inc GST.

Front End

The front of your Outback Explorer Hilux is held up by the Australian Made Heavy Duty Coil Springs coated in the Signature Superior Silver Powder coat. CV Angle Re-Alignment comes courtesy of the Superior 25mm Diff Drop Kit.

Upper Control Arms

All Outback Explorer Kits include a pair of the Australian Made Superior Engineering Billet Upper Control arms, which are designed to assist with correcting wheel alignment through fine-tuning of the camber and castor angles when lifting your IFS vehicle. Manufactured from Solid Billet Aircraft Grade 6000 Series Alloy, these UCA's are manufactured to give additional clearance to the Front Coil Spring during articulation and increased clearance for the Under Guard. Durable Poly Bushes are utilised at the chassis end, alongside the highest quality, high-angle greaseable ball joints at the wheel end, to allow for the maximum range of movement without binding.

Shocks

All Outback Explorer Kits come standard with Superior Engineering 2.0 Remote Reservoir Shock Absorbers Front and Rear, with kit options that include the Superior Engineering 2.5 Remote Reservoir Shocks.

Superior Engineering Remote Reservoir Shock Absorbers feature an external compression adjuster knob as standard across the range, with an additional rebound adjuster feature included exclusively on the 2.5 Inch Bore Shocks. Included are the Hilux-specific Shock Reservoir Mounts front and rear designed to keep your Reservoirs securely fixed out of harm's way.

Wheels, Tyres and Speedo Correction

Superior Engineering 2" Lift Outback Explorer Kits can be legally certified Pre-Registration with tyre sizes up to and including 265/70R17 (31.7 Inches) with Wheel Offsets varying from OE through to POS10. A Superior CANBUS Specific Speedo Correction Module is calibrated to your nominated tyre size and installed to ensure accurate speedometer readings.

Rear End

The centrepiece of all Outback Explorer Leaf Sprung GVM Upgrades is the HD Load Carrying leaves, coupled with polyurethane bushes, greaseable shackles and greasable fixed pins.

Brakes

Superior Outback Explorer Kits include Braided Steel Chassis to Diff Brake Lines in the rear, giving you the confidence that your Hilux has the Braking Performance needed when loaded to your new Gross Vehicle Mass or when articulating off-road.

Chassis Brace

All Leaf Sprung Outback Explorer Packages are equipped with a Weld-On Chassis Brace Kit to support the increased Gross Vehicle Mass.

The Little Things

On top of everything you have seen above, Outback Explorer Kits include a wide range of smaller functional components used to assist in correcting your Suspension and Steering Geometry including Front Sway Bar Relocation Plates. Several other components are included as part of the Approval Process including LED Category-6 Indicators for your Front Guards.

Guard Decals

Superior Engineering has made sure everyone you drive past or park next to knows just what you"re driving when they look up at you, thanks to the Superior Outback Explorer Chrome Guard Decals.

Keep it Legal

Superior Engineering Outback Kits are legal Australia Wide with Federal Approved when fitted before the vehicles first registration. These kits are exclusively available for fitment through Superior Engineering or one of the Federally Approved Production Facilities. Post Registration options are available on selected kits, depending on the State or territory your vehicle is registered in. Please contact your local Superior Engineering Federally Approved Production Facility for Post-Registration Options.

*Cab Chassis Variants are NOT Approved for Outback Explorer Kits

• Outback Explorer GVM Kits are not inclusive of a vehicle - Customer is to supply Superior Engineering with a brand-new unregistered vehicle.
• Outback Explorer GVM Kit Installation prices are based on installation on a brand-new unregistered vehicle only.
• Vehicles may be shown with optional modifications or additional extras/accessories that are not included in Outback Explorer Kits such as Wheels and Tyres.
