The Ultra Winch PDX MK4 Premium Winch is built for serious recovery performance, delivering a 9500 lbs rating in a striking Cosmic Black and Blue finish. As part of the advanced PDX MK4 series, this winch has been engineered to overcome the shortcomings found in many so called premium units, with a focus on stronger wiring, improved connectivity and easier installation. It is designed for drivers who want dependable pulling power, refined control and a premium look to suit modern 4x4 fitouts.

At the heart of the PDX MK4 series is a robust 235:1 three stage planetary gearbox, a rugged 600A IP67 waterproof solenoid and ultra heavy duty 50mm2 wiring with protective black sheathing. The winch includes both wired and wireless hand remotes, a 90 degree rotatable clutch housing for easier access, and a synthetic rope rated to 16,800 lbs with a 25m length and 10.0mm diameter. A fairlead, winch hook with strap and battery isolation switch safety key are also included for a complete installation package.

With pre fitted mounting nuts, updated control box bracket options and mud proof recessed sockets, the PDX MK4 is built for practical fitment and reliable operation in demanding conditions. Backed by strong warranty coverage and designed for enhanced serviceability, this premium winch is ready for touring, recovery and off road confidence.

Features & Benefits

• 9500 lbs recovery capacity for dependable pulling performance
• PDX MK4 series design with upgraded wiring and connectivity
• Wired and wireless hand remote included for flexible control
• 90 degree rotatable clutch housing for easier access
• Lightweight synthetic rope setup for easier handling and installation
• IP67 waterproof solenoid and mud proof sockets for harsh conditions

• Rating: 9500 lbs
• Series: PDX MK4
• Finish: Cosmic Black and Blue
• Gearbox: 235:1 three stage planetary
• Solenoid: 600A, IP67 waterproof
• Rope: 25m x 10.0mm synthetic rope
• Rope rating: 16,800 lbs
• Remote controls: Wired and wireless hand remote included
• Clutch housing: 90 degree rotatable design
• Weight: 20.16kg with synthetic rope
• Weight: 22.5kg with controller box, wiring and bolts
• Warranty: Lifetime mechanical, 7 year electrical, 7 year water ingress
