The Ultra Winch PDX MK4 Premium Winch is built for serious recovery performance, combining advanced engineering with a refined premium finish. Part of the PDX MK4 series, this 9500 lb winch delivers dependable pulling power for 4WD owners who want strength, durability, and improved installation flexibility in one package. Finished in Arctic White with Black and Orange details, it brings a bold, modern look to your bull bar setup.

Designed with an all alloy construction, the PDX MK4 series offers a lighter weight package without compromising strength. The upgraded 50mm2 cross sectional wiring with black protective sheathing is made to reduce resistance and support demanding electrical loads, while the rugged 600A IP67 waterproof solenoid helps maintain reliable performance in harsh conditions. Its 90 degree rotatable clutch housing improves access, and the updated control box bracket, pre fitted mounting nuts, and refined terminal layout make fitment and servicing more straightforward.

With wired and wireless remote control options, a 235:1 three stage planetary gearbox, and a 25m synthetic rope rated to 16,800 lbs, this winch is ready for confident recovery work. The included fairlead, hook with strap, and battery isolation safety key add practical value, while the lightweight design helps keep installation manageable. Built for performance and backed by strong warranty coverage, the PDX MK4 is a premium recovery solution for demanding adventures.

Features & Benefits

• 9500 lb rated pulling capacity for reliable recovery performance
• PDX MK4 series design with all alloy construction for strength and reduced weight
• Ultra heavy duty 50mm2 wiring for improved electrical efficiency
• Rugged 600A IP67 waterproof solenoid for harsh weather protection
• Wired and wireless hand remote included for flexible operation
• 90 degree rotatable clutch housing for easier access and servicing

• Rated capacity: 9500 lbs
• Series: PDX MK4
• Finish: Arctic White, Black with Orange
• Gearbox: 235:1 three stage planetary
• Rope: 25m x 10.0mm synthetic rope
• Rope rating: 16,800 lbs
• Solenoid: 600A, IP67 waterproof
• Weight: 20.16kg with synthetic rope
• Weight with controller box, wiring and bolts: 22.5kg
• Warranty: Lifetime mechanical, 7 year electrical, 7 year water ingress
