The Ultra Winch PDX MK4 Premium Winch is built for serious recovery performance, combining the proven PDX series design with the latest MK4 upgrades for improved durability, connectivity and ease of use. Rated at 9500 lbs, this premium winch is ideal for 4WD owners who need dependable pulling power in tough off-road conditions, while the Arctic White and Black on Black finish adds a bold, modern look to your bar setup.

Engineered with ultra heavy duty 50mm2 wiring and a rugged 600A solenoid, the PDX MK4 is designed to deliver stronger electrical performance and reduced resistance under load. The 90 degree rotatable clutch housing improves access, while the three stage planetary gearbox provides controlled, efficient operation. With the included wired and wireless hand remotes, plus the new y splitter control system, you get flexible control options to suit in-cab or external mounting preferences.

Practical installation and long term reliability are key strengths of the PDX MK4 series. It comes complete with a synthetic rope, fairlead, hook with strap and battery isolation safety key, making it a complete recovery solution straight out of the box.

Features & Benefits

• 9500 lbs rated capacity for confident vehicle recovery
• PDX MK4 series design with upgraded wiring and control connectivity
• 90 degree rotatable clutch housing for easier access
• Wired and wireless hand remotes included for versatile operation
• 600A waterproof solenoid for demanding off road conditions
• Synthetic rope setup with included fairlead and hook strap for ready to install convenience

• Rated capacity: 9500 lbs
• Series: PDX MK4
• Finish: Arctic White and Black on Black
• Gearbox: 235 to 1 three stage planetary
• Rope length: 25 m
• Rope diameter: 10.0 mm
• Rope rating: 16,800 lbs
• Solenoid: 600A IP67 waterproof
• Control options: Wired and wireless hand remote
• Includes: Fairlead, winch hook with strap, battery isolation switch
• Warranty: Lifetime mechanical, 7 year electrical, 7 year water ingress
• Weight: 20.16 kg with synthetic rope
